Master Rebuild kit for CRL-J-JL-K16
SKU: CRL-J-JL-K16-MRK ★★★★★ (132 reviews)
Pick your vehicle to confirm fit

546.00 546.0 USD 546.00

546.00

Not Available For Sale

See financing options →

Fitment guarantee Ships from Orem, UT 4–8 hr install
https://core4x4.com/web/image/product.template/27140/image_1920?unique=2d5d26f

Master Rebuild kit for CRL-J-JL-K16

Master Rebuild kit for CRL-J-JL-K16
SKU: CRL-J-JL-K16-MRK
Pick your vehicle to confirm fit

546.00 546.0 USD 546.00

546.00

Not Available For Sale

Compare all tiers →

Select Color to see price and add to cart.

Lifetime warranty on all non-wear items United States

Made in USA Orem, Utah
Lifetime Guarantee Unconditional
10 Colors In-house powder coat
Fully Adjustable 0-6" of lift
3 X-Series Options Only Core 4x4

Everything you need to refresh your suspension.

This rebuild kit includes all the essential components needed to replace common wear items and restore performance.

CE-9110RK × 8

CE-9110NRK × 4

CE-9112NRK × 1
4

Make Model Submodel Years
Jeep Wrangler 2018 - Present

Construction & Materials

Jeep Wrangler JL / JLU 18+ 16pc Crawl Series Adjustable Control Arm, Track Bar, Steering, End Link Kit

Front Lower control arm built with 1.75” OD 5/16” Wall DOM. Welded Johnny Joint on the fixed end and a Forged Johnny Joint on the adjustable end with 1.25” x 12 TPI - 2.625” long threads.

Front Upper control arm built with 1.5” OD 5/16” Wall DOM. Welded u-bracket on the welded end and a Forged Johnny Joints on the adjustable end with 1” x 14” TPI - 2.32” long threads.

Rear Lower control arm built with 1.75” OD 5/16” Wall DOM. Forded Johnny Joints on both adjustable ends with 1.25” x 12 TPI - 2.625” long threads.

Rear Upper control arm built with 1.5” OD 5/16” Wall DOM. Forged Johnny Joints on both adjustable ends with 1” x 14 TPI - 2.32” long threads.

Front Track Bar built with 1.5” OD 5/16” Wall DOM. Welded Johnny Joint on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14 TPI - 2.32” long threads.

Rear Track Bar built with 1.5” OD 5/16” Wall DOM. Welded Johnny Joint on the fixed end and a Forged Johnny Joints on the adjustable end with 1” x 14 TPI - 2.32” long threads.

Front End Links built with .75” Cold Rolled Steel. Welded Johnny Joints on both fixed ends.

Rear End Links built with .75” Cold Rolled Steel. Welded Johnny Joints on both fixed ends.

Tie Rod and Drag Link made from 2" 7075 Aluminum. Tie Rod and Drag Link use Apex Chassis Forged Rod Ends.
