Everything you need to refresh your suspension.
This rebuild kit includes all the essential components needed to replace common wear items and restore performance.
CE-9110RK × 4
CE-9112NRK × 3
This listing includes all 3 required units.
BSH-CB-2579 × 4
BSH-CB-7087 × 3
This listing includes all 3 required units.
| Make | Model | Submodel | Years |
|---|---|---|---|
| Dodge/Ram | 1500 | 2009 - Present |
Construction & Materials
Ram 1500 09+ 7pc Trail Series Rear Adjustable Control Arm, Track Bar, End Link Kit
Rear Upper Control Arms Built With 1.75” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joint on the adjustable end with 1.25” x 12 TPI - 2.625” long threads.
Rear Lower Control Arm Built With 1.75” OD 5/16” Wall DOM. A Polyurethane Bushing on the fixed end and a Forged Johnny Joint on the adjustable end with 1.25” x 12 TPI - 2.625” long threads.
Rear Track Bar Built With 1.5” OD 5/16” Wall DOM. Polyurethane Bushing on the fixed end and a Forged Johnny Joint on the adjustable end with 1” x 14 TPI - 2.32” long threads.
Reviews of Core 4x4
5.0
★
★
★
★
★
132 reviews
MN
Mike Nielsen
Nov 23, 2025
★
★
★
★
★
The customer service is first class. I had an issue with a track bar I installed on my F350. I don’t have any other Core 4x4 parts yet, but with the way I was treated, I know their parts are well done, because they went above and beyond to make sure I was made whole. They wouldn’t be in business if they had to take care of a lot of people like they took care of me. Will definitely be back when it’s time to build the Jeep!
JS
Jon Stempien
May 27, 2025
★
★
★
★
★
Big thanks to Corby at core 4 x 4 outstanding customer service I like to thank them or 4 x 4 for helping me Well-made product in the United States recommend core 4 x 4 for all jeep Owners that like the four wheel
CL
Cade Leith
Mar 23, 2024
★
★
★
★
★
Have full upper/lower CA set on both front and rear axles on a 96 ZJ. These are the rubber bushing sets not joint sets. I have beat the hell out it in the Nevada desert for 2 years and has been great. I don’t go fast but I do articulate suspension a lot. Super solid and haven’t any issues. Just inspected the entire set recently due to some banging under it. Turns out the banging is lower rear shock bushings. Inspected each CA along the way nothing. Aside from dirt and obviously winter roads and what not still in excellent condition, bushings are solid like the day they were installed. I’ll add that I’m about tapped on a short arm at 4.25(less with settle) so the front CA’s get beat on just from that, still they’re like new. Paint is great condition, this set is red. I would definitely buy again. Another plus for me, Utah isn’t local necessarily, but it’s nice to support businesses closer to me.
AL
Aaron Lake
Apr 27, 2025
★
★
★
★
★
Korby was a great help with getting me a set of leaf springs for my Cherokee. Great customer service and an awesome product all made in the USA. Proud to support and rock their parts on my vehicle. 👍 …
VK
Victor Keele
Sep 24, 2025
★
★
★
★
★
Great customer service. I got my front upper and lower control arms and hardware on Friday afternoon. It didn’t come with instructions so I called Core 4X4 and they immediately e mailed me the instructions. Also, the kit I got had the spacers missing so I called. It was late Friday by thus time but they took care of the issue first thing Monday morning and I got the spacers on Tuesday. Great company.
AM
Adam M
Sep 24, 2025
★
★
★
★
★
First time buying from Korby @ Core 4x4 and it’s being nothing short of a great experience. I bought the non adjustable Trail kit for my 5th Gen Ram 1500 with a 2” lift. The welds look great, nice powder coat finish and quality bushing. Had some trouble fitting the grease nipples due to the powder coating but a thread tap would fix that. They fit easily and perform great. I felt the improvement straight away. No more wheel hop on hard acceleration which was my main reason for the purchase.
I was missing some smaller bushings needed for the 5th Gen and Korby’s custom service was on point, with responsive emails and mailing out the missing parts straight away. Very happy with their products and customer service. Highly recommended company👌🏽
LM
Logan Matejek
May 27, 2025
★
★
★
★
★
The parts are a massive improvement over factory. I accidentally ordered the wrong endlinks and they helped me figure out the correct size and sent me new ones.
Definitely an awesome store
DR
David Rogers
Aug 25, 2025
★
★
★
★
★
Ive had the front adjustable control arm kit in bright green for my 1996 ZJ.
Ive had the kit for about a year now and i have to say, im extremely impressed, over 1000 miles off-road and roughly 20,000 miles on the highway. These control arm kits for any vehicle built by core 4x4 are well worth the money, just be aware thereight be some minor scatches or chips from shipping ( but who should care about that if you're beating the crap out of em' they way they were built and designed for)
N
niceguyr1
Mar 24, 2023
★
★
★
★
★
I purchased upper and lower adjustable arms for my WJ and lowers were missing the spacers. I didn't know until 3 months later when I was installing them. With absolutely zero hassles they quickly sent me the missing spacers. Fantastic product and service! Huge thank you guys for the awesome service and parts!!! Customer service is quickly becoming a lost commodity and you guys gave me hope that it's still alive and well, you just have to buy from the right people... Thanks again for going above and beyond! 👍👍
L
luke
Mar 24, 2021
★
★
★
★
★
Excellent quality product and service. My l lower control arms broke and within the same day core 4x4 hooked me up with tier 2 arms and with the color I wanted. My Jeep rides better and has been solid for several months so far. 10/10 would recommend their products to anyone.
